Airmax Trumpet Fountain Nozzle
The Airmax Trumpet Fountain Nozzle sends a tall, narrow column of water straight up from your Airmax fountain. It is the tallest of the Airmax patterns on every model, and its slim footprint keeps the spray inside the edges of smaller ponds. Choose your fountain and you get the trumpet nozzle made for that model and horsepower.
• Tall Center Column: Up to 17′ high on the PondSeries 2 HP and 16′ on the SolarSeries and PondSeries 1 HP.
• Narrow Footprint: Only 5′ to 7′ wide, so it suits small or irregular ponds.
• No Tools Needed: Change patterns with the nozzle nut on your existing fountain.
• Made for Airmax Fountains: Fits the EcoSeries 1/2 HP, SolarSeries, and PondSeries 1/2, 1 and 2 HP fountains.
Trumpet Pattern Nozzle Spray Height and Width by Fountain
| Fountain | Spray Height × Width |
| EcoSeries 1/2 HP | 14′ H × 7′ W |
| SolarSeries | 16′ H × 6′ W |
| PondSeries 1/2 HP | 12.5′ H × 5′ W |
| PondSeries 1 HP | 16′ H × 6′ W |
| PondSeries 2 HP | 17′ H × 7′ W |
Airmax EcoSeries, SolarSeries and PondSeries Trumpet Nozzle Part Numbers
| Fountain | Airmax Part # |
| EcoSeries 1/2 HP | 651708 |
| SolarSeries | 651907 |
| PondSeries 1/2 HP | 651887 |
| PondSeries 1 HP | 651907 |
| PondSeries 2 HP | 651897 |
Before You Order an Airmax Trumpet Nozzle
- Match the nozzle to your fountain model and horsepower. PondSeries 1/2, 1 and 2 HP nozzles are not interchangeable.
- The SolarSeries and the PondSeries 1 HP use the same trumpet nozzle, part 651907.
- Every EcoSeries, SolarSeries and PondSeries fountain ships with 3 standard patterns. Order this nozzle to add a pattern or replace a lost or damaged one.
- Installs without tools: unscrew the nozzle nut, swap the nozzle and tighten the nut.
- Spray sizes are Airmax's 2026 specifications. Actual height and width vary with conditions.
- Want a wider display? See the Crown & Trumpet nozzle, the Arch nozzles (Single Arch, Double Arch, Double Arch & Geyser) or the Blossom (Crown & Arch) nozzle.
- Not sure which fountain you have? Contact us with your fountain model and we will confirm the right nozzle.
Airmax Fountain Nozzle Installation Manual
- FREE Shipping via FEDEX, LTL Ground, & UPS. Ships in 2-3 Business Days.
- Ships Only to Lower 48 States of the United States
