Transform Your Yard with Aquascape Swimming Pond 9' x 20'
The Aquascape Recreational Pond Kit 9' x 20' includes every major component you need to create a clear, healthy, and beautiful swimming-style pond. No guesswork, no piecing equipment together — just install and enjoy crystal-clean water and natural ecosystem filtration.
• Complete Turnkey System: All major pond components are bundled together to eliminate confusion and compatibility issues.
• Naturally Clear Water: Wetland filtration and an intake bay work together to remove debris, sediments, and impurities from surface to bottom.
• Strong, Consistent Waterflow: The EXT 12000 pump keeps water continuously moving for healthier circulation and better clarity.
• Low-Maintenance Ecosystem: Biological filtration supports clean, self-sustaining water that’s gentle on fish and safe for families.
• Perfect for Swimming & Relaxing: The 9' x 20' deep-water zone gives you space to dip, float, and enjoy a resort-style backyard experience.
Enjoy Crystal-Clear Water with a Recreational Pond Kit 9x20
The Aquascape Recreational Pond Kit 9' x 20' makes water care simple with intelligent filtration and automated treatment systems that take the stress out of maintenance.
• Automatic Surface Cleaning: The intake bay constantly skims leaves and debris before they sink and cloud your water.
• Multi-Stage Filtration Protection: AquaBlox® and Centipede® modules push water through multiple layers for long-term cleanliness.
• Effortless Algae Control: The IonGen™ System G2 helps reduce algae naturally, without constant chemical dosing.
• Set-It-and-Forget-It Treatment: Smart Pond Dosing XT automatically adds beneficial treatments to maintain balanced water chemistry.
• Heavy-Duty Leak Prevention: Thick 45-mil EPDM liner and full underlayment protect against punctures, shifting stones, and plant roots.
What Makes the Recreational Pond Kit 9x20 by Aquascape Unique
• No Sizing Calculations Needed: Piping, pump kits, vaults, and liners are all properly sized and flow-matched for this exact 9' x 20' build.
• Ready for Install Day: The Water Feature Installation Kit saves multiple trips to the hardware store.
• Built to Last Years Outdoors: Snorkel® vaults, pump fittings, and reinforced rock pads withstand constant water pressure and weather changes.
• Premium Materials Stay Flexible: Professional EPDM liner and flexible PVC pipe prevent cracking and resist aging.
• Customizable Design Options: Supports waterfalls, jets, natural stone edging, and different pond layouts for a signature backyard look.
Aquascape Recreational Pond Kit 9' x 20': What Comes in the Box
Everything you need comes standard with your Recreational Pond Kit 9' x 20'!
- Pondless® Waterfall Vault
- Pondless® Waterfall Vault Extension
- Large Snorkel® Vault and Cap
- Large Snorkel® Vault Extension
- Large Centipede® Module
- Half Centipede® Module
- AquaBlox® Water Storage Module – Small
- AquaBlox® Water Storage Module – Large
- EXT 12000 Pond Pump
- Flexible PVC Pipe 3″ x 50′
- Flexible PVC Pipe 2″ x 25′
- EXT Pump 2″-3″ Plumbing Kit
- 45 mil EPDM Liner Roll – 25′ x 50′
- 45 mil EPDM Liner Boxed – 20′ x 25′
- Non-Woven Geotextile Underlayment – 15′x100′ (1,500 sq ft)
- Rock Pad Roll – 15’x150′
- Smart Pond Dosing System XT
- Maintain for Ponds XT – 1 Gal
- IonGen™ System G2
- Water Feature Installation Kit
- Installation Manuals
Aquascape Recreational Pond Kit 9' x 20' Technical Specifications
| Feature | Detail |
| Pond Size | 9' x 20' deep-water zone (2.74 m x 6.10 m) |
| Wetland Filter | 7.5' x 11' (2.29 m x 3.35 m) |
| Intake Bay | 5' x 6' (1.52 m x 1.83 m) |
| Pump | EXT 12000 External Pond Pump |
| Pump Flow | Approx. 12,000 GPH (45,424 LPH) |
| Liner (Roll) | 45-mil EPDM • 25' x 50' (7.62 m x 15.24 m) |
| Liner (Boxed) | 45-mil EPDM • 20' x 25' (6.10 m x 7.62 m) |
| Underlayment | 15' x 100' (4.57 m x 30.48 m) |
| Rock Pad Roll | 15' x 150' (4.57 m x 45.72 m) |
| PVC Pipe (3") | 3" x 50' (7.62 cm x 15.24 m) |
| PVC Pipe (2") | 2" x 25' (5.08 cm x 7.62 m) |
| Plumbing Kit | EXT Pump 2"-3" Plumbing Kit |
| Water Treatment | Smart Pond Dosing XT + Maintain for Ponds XT (1 gal / 3.78 L) |
| Algae Control | IonGen™ System G2 |
| Installation Kit | Water Feature Installation Kit included |
Aquascape Recreational Pond Kit 9' x 20' Manuals:
